Triumph 650cc 1968 - 1969

$13.95

Description

11" x 17" Hard Copy Laminated Color Wiring Diagram in Factory Colors   (One Page)

Twin Motorcycles with Engine Numbers Between DU66236 AND DUXXXXX

Triumph Twin Engine & Frame Numbers - Unlocking the Mystery.  (My thanks to the BBC for the following info).

  1950 through 1969:

  Year Unit 350cc & 500cc

Pre-unit 500cc & 650cc


  1950 n/a From 100 N
  1951 n/a 101NA - 15,808NA
  1952 n/a 15,809NA - 25,000NA then 25,000 - 32,302
  1953 n/a 32,303 - 44,134
  1954 n/a 44,135 - 56,699
  1955 n/a 56,700 - 82,799
  1956 n/a 70,930 - 011,115 then 0100 - 0944
  1957 H101 - H760 0945 - 011,116
  1958 H761 - H5,484 011,116 - 020,075
  1959 H5,484 - H11,511 020,076 - 029,363
  1960 H11,512 - H18,611 029,364 - 030,424 then D101 - D7726
  1961 H18,612 - H25,251 D7,727 - D15,788
  1962 H25,252 - H29,732 D15,789 on Unit 650cc
  1963 H29,733 - H32,464 DU101 - DU5,824
  1964 H32,465 - H35,986 DU5,825 - DU13,374
  1965 H35,987 - H40,527 DU13,375 - DU24,874
  1966 H40,528 - H49,832 DU24,875 - DU44,393
  1967 H49,833 - H57,082 DU44,394 - DU66,245
  1968 H57,083 - H65,572 DU66246 - DU85,903
  1969 H65,573 - H67,331 DU85,904 - DU90,282


1969 Forward:

The models produced after 1969 contained the same prefix designators listed above, that indicated the model type, but the numbers were changed.  A new coding system (numbers) was introduced using a two letter prefix for the month and the model season year, followed by a number which began at 00,100 for each model year and on irrespective of the model it was stamped on (Bonneville, Tiger, etc).  The model season started in August.

For example, a bike manufactured in December of 1971 might be numbered XE11,111.

First letter (month of manufacture):


 A January
B February

C March
D April

E May
G June

H July
J August

K September
N October

P November
X December










 Letter Period Year

C October 1968 - July 1969 1969

D August 1969 - July 1970 1970

E October 1970 - July 1971 1971

G August 1971 - July 1972 1972

H August 1972 - June 1973 1973

J August 1973 - October 1974 1974

K April 1974 - June 1975 1975

N July 1975 - June 1976 1976

P June 1976 - August 1977 1977

X July 1977 - August 1978 1978

A July 1978 - November 1979 1979

B August 1979 - July 1980 1980

DA August 1979 - July 1980 1980

DA September 1980 - August 1981 1981

DA May 1981 - February 1982 1982

EA February 1982 - January 1983 1983
